2N1523
View detailed images (13)

2N1523

SKU: 2N1523
2N1523 Transistor Germanium PNP CASE: TO36 MAKE: USA Make
Price:
£23.99 Inc. VAT (£19.99 Ex. VAT)
£23.99 Inc. VAT (£19.99 Ex. VAT)
Qty
  • 5 pieces in 1-2 Days
  • More pieces shipped in 14 days
?
Product specifications
Type Transistor Germanium PNP
Case TO36
Manufacturer USA Make
Vbr CBO 80
Vbr CEO 60
Max. PD (W) 70
Max. hFE 100
Min hFE 25
Ic Max. (A) 50
@Ic (test) (A) 15
Icbo Max. @Vcb Max. (A) 100u
Polarity PNP
Derate Above 25°C 1.2
Oper. Temp (°C) Max. 95
@VCE (V) 4.0
Pinout Equivalence Number 3-14
Surface Mounted Yes/No NO
Maximum Collector Power Dissipation (Pc) 75 W
Maximum Collector-Base Voltage |Vcb| 80 V
Maximum Collector-Emitter Voltage |Vce| 60 V
Maximum Emitter-Base Voltage |Veb| 30 V
Maximum Collector Current |Ic max| 50 A
Max. Operating Junction Temperature (Tj) 85 °C
Transition Frequency (ft): 0.04 MHz
Forward Current Transfer Ratio (hFE), MIN 25
SKU 605876
