2N167A
View detailed images (4)

2N167A

SKU: 2N167A
2N167A Transistor Germanium NPN CASE: TO22 MAKE: Generic
Price:
£5.75 Inc. VAT (£4.79 Ex. VAT)
£5.75 Inc. VAT (£4.79 Ex. VAT)
Qty
  • 9 pieces in 1-2 Days
  • More pieces shipped in 14 days
?
Product specifications
Type Transistor Germanium NPN
Case TO22
Manufacturer Generic
Vbr CBO 30
Vbr CEO 30
Max. PD (W) 75m
C(ob) (F) 6.0p
Derate (Amb) (W/°C) 1.1m
Ic Max. (A) 75m
Icbo Max. @Vcb Max. (A) 1.5u
Polarity NPN
Trans. Freq (Hz) Min. 5.0M
Oper. Temp (°C) Max. 85
Pinout Equivalence Number N/A
Surface Mounted Yes/No NO
Maximum Collector Power Dissipation (Pc) 0.065 W
Maximum Collector-Base Voltage |Vcb| 30 V
Maximum Collector-Emitter Voltage |Vce| 30 V
Maximum Emitter-Base Voltage |Veb| 5 V
Maximum Collector Current |Ic max| 0.025 A
Max. Operating Junction Temperature (Tj) 75 °C
Collector Capacitance (Cc) 9 pF
Transition Frequency (ft): 4 MHz
Forward Current Transfer Ratio (hFE), MIN 30
SKU 776740
