2N2223A
View detailed images (12)

2N2223A

SKU: 2N2223A
2N2223A Transistor Silicon NPN CASE: TO77 MAKE: Semelab
Price:
£23.99 Inc. VAT (£19.99 Ex. VAT)
£23.99 Inc. VAT (£19.99 Ex. VAT)
Qty
  • More pieces shipped in 14 days
?
Datasheet
2N2223A Datasheet
Product specifications
Type Transistor Silicon NPN
Case TO77
Manufacturer Semelab
Vbr CBO 100
Vbr CEO 60
Max. PD (W) 500m
C(ob) (F) 15p
Derate (Amb) (W/°C) 2.8m
hfe 40
Ic Max. (A) 500m
Icbo Max. @Vcb Max. (A) 10n
Polarity NPN
Trans. Freq (Hz) Min. 50M
@VCE (test) (V) 5.0
Oper. Temp (°C) Max. 175
@Ic (A) 1.0m
Pinout Equivalence Number 7-16
Surface Mounted Yes/No NO
Maximum Collector Power Dissipation (Pc) 0.6 W
Maximum Collector-Base Voltage |Vcb| 100 V
Maximum Collector-Emitter Voltage |Vce| 60 V
Maximum Emitter-Base Voltage |Veb| 7 V
Maximum Collector Current |Ic max| 0.5 A
Max. Operating Junction Temperature (Tj) 200 °C
Collector Capacitance (Cc) 15 pF
Transition Frequency (ft): 50 MHz
Forward Current Transfer Ratio (hFE), MIN 50
SKU 116106
