2N4429
View detailed images (8)

2N4429

SKU: 2N4429
2N4429 Transistor Silicon NPN CASE: TO117 MAKE: TRW Vertriebs
Price:
£57.59 Inc. VAT (£47.99 Ex. VAT)
£57.59 Inc. VAT (£47.99 Ex. VAT)
Qty
  • More pieces shipped in 14 days
?
Datasheet
2N4429 Datasheet
Product specifications
Type Transistor Silicon NPN
Case TO117
Manufacturer TRW Vertriebs
Vbr CBO 55
Vbr CEO 35
Max. PD (W) 5.0
Max. hFE 200
Min hFE 20
Ic Max. (A) 425m
@Ic (test) (A) 50m
Icbo Max. @Vcb Max. (A) 1.0m
Polarity NPN
Derate Above 25°C 28m
Oper. Temp (°C) Max. 175
@VCE (V) 5.0
Pinout Equivalence Number 4-28
Surface Mounted Yes/No NO
Maximum Collector Power Dissipation (Pc) 5 W
Maximum Collector-Base Voltage |Vcb| 55 V
Maximum Collector-Emitter Voltage |Vce| 35 V
Maximum Emitter-Base Voltage |Veb| 3 V
Maximum Collector Current |Ic max| 0.425 A
Max. Operating Junction Temperature (Tj) 175 °C
Collector Capacitance (Cc) 3.5 pF
Transition Frequency (ft): 700 MHz
Forward Current Transfer Ratio (hFE), MIN 20
SKU 82093
