2N4946
View detailed images (12)

2N4946

SKU: 2N4946
2N4946 Transistor Silicon NPN CASE: TO98 MAKE: Fairchild Semiconductor
Price:
£5.75 Inc. VAT (£4.79 Ex. VAT)
£5.75 Inc. VAT (£4.79 Ex. VAT)
Qty
  • 15 pieces in 1-2 Days
  • More pieces shipped in 14 days
?
Product specifications
Type Transistor Silicon NPN
Case TO98
Manufacturer Fairchild Semiconductor
Vbr CBO 75
Vbr CEO 40
Max. PD (W) 220m
C(ob) (F) 8.0p
t(on) Delay (S) 10n
Derate (Amb) (W/°C) 2.2m
t(f) Max. (S) 60n
hfe 100
Ic Max. (A) 500m
Icbo Max. @Vcb Max. (A) 10n
Polarity NPN
Tr Max. (s) 25n
t(stor) Max. (S) 225n
Trans. Freq (Hz) Min. 300M
@VCE (test) (V) 10
Oper. Temp (°C) Max. 150
@Ic (A) 150m
Pinout Equivalence Number 3-12
Surface Mounted Yes/No NO
Maximum Collector Power Dissipation (Pc) 0.6 W
Maximum Collector-Base Voltage |Vcb| 80 V
Maximum Collector-Emitter Voltage |Vce| 40 V
Maximum Emitter-Base Voltage |Veb| 5 V
Maximum Collector Current |Ic max| 0.5 A
Max. Operating Junction Temperature (Tj) 125 °C
Collector Capacitance (Cc) 25 pF
Transition Frequency (ft): 60 MHz
Forward Current Transfer Ratio (hFE), MIN 100
SKU 313009
