2N5309
View detailed images (12)

2N5309

SKU: 2N5309
2N5309 Transistor Silicon NPN CASE: TO98 MAKE: Motorola Semiconductor
Price: £4.79
+ VAT 20% for UK purchases
£4.79
Qty
+ VAT 20% for UK purchases
  • 2 pieces in 1-2 Days
  • More pieces shipped in 14 days
?
Product specifications
Type Transistor Silicon NPN
Case TO98
Manufacturer Motorola Semiconductor
Vbr CBO 70
Vbr CEO 50
Max. PD (W) 330m
Derate (Amb) (W/°C) 3.3m
hfe 66
Ic Max. (A) 100m
Icbo Max. @Vcb Max. (A) 10n
Polarity NPN
@VCE (test) (V) 5.0
Oper. Temp (°C) Max. 150
@Ic (A) 10u
Pinout Equivalence Number 3-10
Surface Mounted Yes/No NO
Maximum Collector Power Dissipation (Pc) 0.36 W
Maximum Collector-Base Voltage |Vcb| 70 V
Maximum Collector-Emitter Voltage |Vce| 50 V
Maximum Emitter-Base Voltage |Veb| 5 V
Maximum Collector Current |Ic max| 0.1 A
Max. Operating Junction Temperature (Tj) 125 °C
Collector Capacitance (Cc) 6 pF
Transition Frequency (ft): 100 MHz
Forward Current Transfer Ratio (hFE), MIN 100
SKU 313065
