2N6021
View detailed images (12)

2N6021

SKU: 2N6021
2N6021 Transistor Silicon PNP CASE: TO220AA MAKE: Semitronics
Product specifications
Type Transistor Silicon PNP
Case TO220AA
Manufacturer Semitronics
Vbr CBO 80
Vbr CEO 70
Max. PD (W) 36
Derate (Amb) (W/°C) 288m
Max. hFE 120
Min hFE 30
Ic Max. (A) 4.0
@Ic (test) (A) 500m
Icbo Max. @Vcb Max. (A) 100m
Polarity PNP
Oper. Temp (°C) Max. 140
@VCE (V) 4.0
Pinout Equivalence Number 4-30
Surface Mounted Yes/No NO
Maximum Collector Power Dissipation (Pc) 36 W
Maximum Collector-Base Voltage |Vcb| 80 V
Maximum Collector-Emitter Voltage |Vce| 70 V
Maximum Emitter-Base Voltage |Veb| 7 V
Maximum Collector Current |Ic max| 4 A
Max. Operating Junction Temperature (Tj) 150 °C
Transition Frequency (ft): 0.8 MHz
Forward Current Transfer Ratio (hFE), MIN 30
SKU 573416
