2SA1301
View detailed images (4)

2SA1301

SKU: 2SA1301
2SA1301 Transistor Silicon PNP - CASE: TO3PL MAKE: Toshiba
Price: £11.99
+ VAT 20% for UK purchases
£11.99
Qty
+ VAT 20% for UK purchases
  • More pieces shipped in 14 days
?
Datasheet
2SA1301 Datasheet
Product specifications
Type Transistor Silicon PNP
Case TO3PL
Manufacturer Toshiba
Vbr CBO 160
Vbr CEO 160
Max. PD (W) 120
Max. hFE 160
Min hFE 55
Ic Max. (A) 12
@Ic (test) (A) 1.0
Icbo Max. @Vcb Max. (A) 5.0u
Polarity PNP
Trans. Freq (Hz) Min. 30M
Oper. Temp (°C) Max. 140
@VCE (V) 5.0
Pinout Equivalence Number 3-15
Surface Mounted Yes/No NO
Maximum Collector Power Dissipation (Pc) 120 W
Maximum Collector-Base Voltage |Vcb| 160 V
Maximum Collector-Emitter Voltage |Vce| 160 V
Maximum Emitter-Base Voltage |Veb| 5 V
Maximum Collector Current |Ic max| 12 A
Max. Operating Junction Temperature (Tj) 175 °C
Collector Capacitance (Cc) 480 pF
Transition Frequency (ft): 30 MHz
Forward Current Transfer Ratio (hFE), MIN 55
SKU 16808
