2SA1688
View detailed images (12)

2SA1688

SKU: 2SA1688
2SA1688 Transistor - Case: SOT323 Make: Sanyo Semiconductor
+ VAT 20% for UK purchases
Datasheet
2SA1688 Datasheet
Product specifications
Type Transistor Silicon PNP
Case SOT323
Manufacturer Sanyo Semiconductor
Vbr CBO 30
Vbr CEO 20
Max. PD (W) 150m
hfe 60
Ic Max. (A) 30m
Icbo Max. @Vcb Max. (A) 100n
Polarity PNP
Trans. Freq (Hz) Min. 230M-
@VCE (test) (V) 6.0
Oper. Temp (°C) Max. 150
@Ic (A) 1.0m
Pinout Equivalence Number 3-12
Surface Mounted Yes/No YES
Maximum Collector Power Dissipation (Pc) 0.15 W
Maximum Collector-Base Voltage |Vcb| 30 V
Maximum Collector-Emitter Voltage |Vce| 20 V
Maximum Emitter-Base Voltage |Veb| 5 V
Maximum Collector Current |Ic max| 0.03 A
Max. Operating Junction Temperature (Tj) 125 °C
Collector Capacitance (Cc) 1.7 pF
Transition Frequency (ft): 230 MHz
Forward Current Transfer Ratio (hFE), MIN 60
SMD Transistor Code E3_E4_E5
