2SA1807
View detailed images (8)

2SA1807

SKU: 2SA1807
2SA1807 Transistor Silicon PNP CASE: TO252 MAKE: Rohm Semiconductor
Datasheet
2SA1807 Datasheet
Product specifications
Type Transistor Silicon PNP
Case TO252
Manufacturer Rohm Semiconductor
Vbr CEO 600
Max. PD (W) 10
Max. hFE 180
Min hFE 56
Ic Max. (A) 2
@Ic (test) (A) 100m
Polarity PNP
@VCE (V) 5
Pinout Equivalence Number 3-15
Surface Mounted Yes/No YES
Maximum Collector Power Dissipation (Pc) 10 W
Maximum Collector-Base Voltage |Vcb| 600 V
Maximum Collector-Emitter Voltage |Vce| 600 V
Maximum Emitter-Base Voltage |Veb| 7 V
Maximum Collector Current |Ic max| 1 A
Max. Operating Junction Temperature (Tj) 150 °C
Collector Capacitance (Cc) 40 pF
Transition Frequency (ft): 15 MHz
Forward Current Transfer Ratio (hFE), MIN 56
SMD Transistor Code TL
SKU 343155
