2SA754
View detailed images (12)

2SA754

SKU: 2SA754
2SA754 Transistor Silicon PNP CASE: TO220AA MAKE: Hitachi
Product specifications
Type Transistor Silicon PNP
Case TO220AA
Manufacturer Hitachi
Vbr CBO 50
Vbr CEO 50
Max. PD (W) 20
Derate (Amb) (W/°C) 160m
Max. hFE 320
Min hFE 35
Ic Max. (A) 2.0
@Ic (test) (A) 1.0
Icbo Max. @Vcb Max. (A) 100u
Polarity PNP
R(sat) (Û) 866m
Trans. Freq (Hz) Min. 50M
Oper. Temp (°C) Max. 140
@VCE (V) 4.0
Pinout Equivalence Number 3-15
Surface Mounted Yes/No NO
Maximum Collector Power Dissipation (Pc) 20 W
Maximum Collector-Base Voltage |Vcb| 50 V
Maximum Collector-Emitter Voltage |Vce| 50 V
Maximum Emitter-Base Voltage |Veb| 6 V
Maximum Collector Current |Ic max| 2 A
Max. Operating Junction Temperature (Tj) 175 °C
Transition Frequency (ft): 20 MHz
Forward Current Transfer Ratio (hFE), MIN 35
SKU 542428
