2SB565A
View detailed images (12)

2SB565A

SKU: 2SB565A
2SB565A Transistor Silicon PNP CASE: TO220AA MAKE: Hitachi
Product specifications
Equivalent 2SB565
Type Transistor Silicon PNP
Case TO220AA
Manufacturer Hitachi
Vbr CBO 70
Vbr CEO 60
Max. PD (W) 40
Derate (Amb) (W/°C) 320m
Max. hFE 320
Min hFE 35
Ic Max. (A) 4.0
@Ic (test) (A) 1.0
Icbo Max. @Vcb Max. (A) 1.0u
Polarity PNP
R(sat) (Û) 500m
Trans. Freq (Hz) Min. 15M
Oper. Temp (°C) Max. 140
@VCE (V) 4.0
Pinout Equivalence Number 3-10
Surface Mounted Yes/No NO
Maximum Collector Power Dissipation (Pc) 40 W
Maximum Collector-Base Voltage |Vcb| 70 V
Maximum Collector-Emitter Voltage |Vce| 60 V
Maximum Emitter-Base Voltage |Veb| 5 V
Maximum Collector Current |Ic max| 4 A
Max. Operating Junction Temperature (Tj) 150 °C
Transition Frequency (ft): 7 MHz
Forward Current Transfer Ratio (hFE), MIN 35
SKU 542907
