2SB705
View detailed images (13)

2SB705

SKU: 2SB705
2SB705 Transistor Silicon PNP CASE: MT200 MAKE: NEC
Price:
£14.39 Inc. VAT (£11.99 Ex. VAT)
£14.39 Inc. VAT (£11.99 Ex. VAT)
Qty
  • 5 pieces in 1-2 Days
  • More pieces shipped in 14 days
?
Datasheet
2SB705 Datasheet
Product specifications
Type Transistor Silicon PNP
Case MT200
Manufacturer NEC
Vbr CBO 140
Vbr CEO 140
Max. PD (W) 120
Derate (Amb) (W/°C) 960m
Max. hFE 200
Min hFE 40
Ic Max. (A) 10
@Ic (test) (A) 2.0
Icbo Max. @Vcb Max. (A) 50u
Polarity PNP
Trans. Freq (Hz) Min. 17M
Oper. Temp (°C) Max. 140
@VCE (V) 5.0
Pinout Equivalence Number 4-33
Surface Mounted Yes/No NO
Maximum Collector Power Dissipation (Pc) 120 W
Maximum Collector-Base Voltage |Vcb| 140 V
Maximum Collector-Emitter Voltage |Vce| 140 V
Maximum Emitter-Base Voltage |Veb| 5 V
Maximum Collector Current |Ic max| 10 A
Max. Operating Junction Temperature (Tj) 150 °C
Collector Capacitance (Cc) 430 pF
Transition Frequency (ft): 9 MHz
Forward Current Transfer Ratio (hFE), MIN 80
SKU 83399
