2SB941
View detailed images (12)

2SB941

SKU: 2SB941
2SB941 Transistor - CASE: SOT186 MAKE: Panasonic
Price: £4.79
+ VAT 20% for UK purchases
£4.79
Qty
+ VAT 20% for UK purchases
  • 16 pieces in 1-2 Days
  • More pieces shipped in 14 days
?
Datasheet
2SB941 Datasheet
Product specifications
Type Transistor Silicon PNP
Case SOT186
Manufacturer Panasonic
Vbr CBO 60
Vbr CEO 60
Max. PD (W) 35
Derate (Amb) (W/°C) 280m
Max. hFE 260
Min hFE 40
Ic Max. (A) 3.0
@Ic (test) (A) 1.0
Icbo Max. @Vcb Max. (A) 200u
Polarity PNP
Tr Max. (s) 1.2u
Oper. Temp (°C) Max. 140
@VCE (V) 4.0
Pinout Equivalence Number 3-15
Surface Mounted Yes/No NO
Maximum Collector Power Dissipation (Pc) 35 W
Maximum Collector-Base Voltage |Vcb| 60 V
Maximum Collector-Emitter Voltage |Vce| 45 V
Maximum Emitter-Base Voltage |Veb| 6 V
Maximum Collector Current |Ic max| 3 A
Max. Operating Junction Temperature (Tj) 150 °C
Forward Current Transfer Ratio (hFE), MIN 100
SKU 80770
