2SB968
View detailed images (8)

2SB968

SKU: 2SB968
2SB968 Transistor Silicon PNP CASE: TO252 MAKE: Matsushita Electronics
Datasheet
2SB968 Datasheet
Product specifications
Type Transistor Silicon PNP
Case TO252
Manufacturer Matsushita Electronics
Vbr CBO 50
Vbr CEO 40
Max. PD (W) 20
Derate (Amb) (W/°C) 160m
Max. hFE 220
Min hFE 50
Ic Max. (A) 1.5
@Ic (test) (A) 1.0
Icbo Max. @Vcb Max. (A) 1.0u
Polarity PNP
Trans. Freq (Hz) Min. 150M
Oper. Temp (°C) Max. 140
@VCE (V) 5.0
Pinout Equivalence Number 3-15
Surface Mounted Yes/No YES
Maximum Collector Power Dissipation (Pc) 20 W
Maximum Collector-Base Voltage |Vcb| 50 V
Maximum Collector-Emitter Voltage |Vce| 50 V
Maximum Emitter-Base Voltage |Veb| 6 V
Maximum Collector Current |Ic max| 1.5 A
Max. Operating Junction Temperature (Tj) 175 °C
Transition Frequency (ft): 75 MHz
Forward Current Transfer Ratio (hFE), MIN 120
SKU 343765
