2SC1409
View detailed images (12)

2SC1409

SKU: 2SC1409
2SC1409 Transistor Silicon NPN CASE: TO220AA MAKE: Hitachi
Product specifications
Equivalent 2SC1409A
Type Transistor Silicon NPN
Case TO220AA
Manufacturer Hitachi
Vbr CBO 200
Vbr CEO 120
Max. PD (W) 12
Max. hFE 200
Min hFE 35
Ic Max. (A) 2.0
@Ic (test) (A) 50m
Icbo Max. @Vcb Max. (A) 10m
Polarity NPN
R(sat) (Û) 3.0
Derate Above 25°C 100m
Oper. Temp (°C) Max. 140
@VCE (V) 4.0
Pinout Equivalence Number 3-15
Surface Mounted Yes/No NO
Maximum Collector Power Dissipation (Pc) 8 W
Maximum Collector-Base Voltage |Vcb| 200 V
Maximum Collector-Emitter Voltage |Vce| 120 V
Maximum Emitter-Base Voltage |Veb| 6 V
Maximum Collector Current |Ic max| 2 A
Max. Operating Junction Temperature (Tj) 150 °C
Collector Capacitance (Cc) 180 pF
Transition Frequency (ft): 10 MHz
Forward Current Transfer Ratio (hFE), MIN 40
SKU 542972
