2SC1418
View detailed images (12)

2SC1418

SKU: 2SC1418
2SC1418 Transistor Silicon NPN CASE: TO220AA MAKE: Hitachi
Price:
£5.75 Inc. VAT (£4.79 Ex. VAT)
£5.75 Inc. VAT (£4.79 Ex. VAT)
Qty
  • 16 pieces in 1-2 Days
  • More pieces shipped in 14 days
?
Product specifications
Type Transistor Silicon NPN
Case TO220AA
Manufacturer Hitachi
Vbr CBO 50
Vbr CEO 50
Max. PD (W) 20
Max. hFE 320
Min hFE 35
Ic Max. (A) 2.0
@Ic (test) (A) 1.0
Icbo Max. @Vcb Max. (A) 100u
Polarity NPN
R(sat) (Û) 866m
Derate Above 25°C 160m
Trans. Freq (Hz) Min. 5.0M
Oper. Temp (°C) Max. 140
@VCE (V) 4.0
Pinout Equivalence Number 3-15
Surface Mounted Yes/No NO
Maximum Collector Power Dissipation (Pc) 20 W
Maximum Collector-Base Voltage |Vcb| 50 V
Maximum Collector-Emitter Voltage |Vce| 50 V
Maximum Emitter-Base Voltage |Veb| 6 V
Maximum Collector Current |Ic max| 2 A
Max. Operating Junction Temperature (Tj) 150 °C
Transition Frequency (ft): 2 MHz
Forward Current Transfer Ratio (hFE), MIN 35
SKU 80891
