2SC2276
View detailed images (13)

2SC2276

SKU: 2SC2276
2SC2276 Transistor Silicon NPN CASE: MT200 MAKE: NEC
Product specifications
Type Transistor Silicon NPN
Case MT200
Manufacturer NEC
Vbr CEO 130
Max. PD (W) 3.0
Max. hFE 320
Min hFE 60
Ic Max. (A) 7.0
@Ic (test) (A) 10
Polarity NPN
@VCE (V) 5.0
Pinout Equivalence Number N/A
Surface Mounted Yes/No NO
Maximum Collector Power Dissipation (Pc) 80 W
Maximum Collector-Base Voltage |Vcb| 130 V
Maximum Emitter-Base Voltage |Veb| 4 V
Maximum Collector Current |Ic max| 7 A
Max. Operating Junction Temperature (Tj) 150 °C
Collector Capacitance (Cc) 150 pF
Transition Frequency (ft): 50 MHz
Forward Current Transfer Ratio (hFE), MIN 150
SKU 765819
