2SC3569
View detailed images (12)

2SC3569

SKU: 2SC3569
2SC3569 Transistor - CASE: SOT186 MAKE: NEC
+ VAT 20% for UK purchases
Datasheet
2SC3569 Datasheet
Product specifications
Type Transistor Silicon NPN
Case SOT186
Manufacturer NEC
Vbr CBO 500
Vbr CEO 400
Max. PD (W) 15
t(f) Max. (S) 1.0u
Max. hFE 80
Min hFE 20
Ic Max. (A) 2.0
@Ic (test) (A) 200m
Icbo Max. @Vcb Max. (A) 10u
Polarity NPN
Tr Max. (s) 1.0u
Oper. Temp (°C) Max. 150
@VCE (V) 5.0
Pinout Equivalence Number 3-15
Surface Mounted Yes/No NO
Maximum Collector Power Dissipation (Pc) 15 W
Maximum Collector-Base Voltage |Vcb| 500 V
Maximum Collector-Emitter Voltage |Vce| 400 V
Maximum Emitter-Base Voltage |Veb| 6 V
Maximum Collector Current |Ic max| 2 A
Max. Operating Junction Temperature (Tj) 125 °C
Forward Current Transfer Ratio (hFE), MIN 55
SKU 344133
