2SC3603
View detailed images (4)

2SC3603

SKU: 2SC3603
2SC3603 Transistor CASE: SOT173 MAKE: NEC
Price:
£7.19 Inc. VAT (£5.99 Ex. VAT)
£7.19 Inc. VAT (£5.99 Ex. VAT)
Qty
  • More pieces shipped in 14 days
?
Datasheet
2SC3603 Datasheet
Product specifications
Type Transistor
Case SOT173
Manufacturer NEC
Vbr CBO 20
@Freq. (test) 2.0G
@Ic (A) 40m
@Ic (A) 20m
Mat. Silicon Logic
Noise Fig. 3.0
Oper. Gain Typ (S21) 9.0
f(osc) Max. (Hz) 7.0G
Polarity NPN
PD Max. (W) 580m
S11 Deg. (Typ) 153
S11 Mag Typ. .62
S22 Deg. Typ. -63
S22 Mag Typ. .19
@VDS (VCE) (test) (V) 10
Coll. (or drain) Current Max. 100m
@Freq. (test) 2.0G
@VCE (test) 10
Oper. Temp (°C) Max. 200
Pinout Equivalence Number 4-34
Surface Mounted Yes/No YES
Maximum Collector Power Dissipation (Pc) 0.58 W
Maximum Collector-Base Voltage |Vcb| 20 V
Maximum Collector Current |Ic max| 0.1 A
Max. Operating Junction Temperature (Tj) 150 °C
Transition Frequency (ft): 7000 MHz
Forward Current Transfer Ratio (hFE), MIN 45
SMD Transistor Code 0
SKU 81157
