2SC3604
View detailed images (4)

2SC3604

SKU: 2SC3604
2SC3604 Transistor - CASE: SOT173 MAKE: NEC
+ VAT 20% for UK purchases
Product specifications
Type Transistor Silicon NPN
Case SOT173
Manufacturer NEC
Vbr CBO 20
@Freq. (test) 2.0G
@Ic (A) 7.0m
@Ic (A) 10m
Mat. Silicon Logic
Noise Fig. 2.5
Oper. Gain Typ (S21) 11
f(osc) Max. (Hz) 9.0G-
Polarity NPN
PD Max. (W) 295m
S11 Deg. (Typ) 171
S11 Mag Typ. .43
S22 Deg. Typ. -44
S22 Mag Typ. .44
@VDS (VCE) (test) (V) 8.0
Coll. (or drain) Current Max. 65m
@Freq. (test) 2.0G
@VCE (test) 8.0
Oper. Temp (°C) Max. 150
Pinout Equivalence Number 3-14
Surface Mounted Yes/No YES
Maximum Collector Power Dissipation (Pc) 0.58 W
Maximum Collector-Base Voltage |Vcb| 20 V
Maximum Collector Current |Ic max| 0.065 A
Max. Operating Junction Temperature (Tj) 150 °C
Transition Frequency (ft): 8000 MHz
Forward Current Transfer Ratio (hFE), MIN 30
SMD Transistor Code 2
SKU 557068
