2SD1020
View detailed images (4)

2SD1020

SKU: 2SD1020
2SD1020 Transistor Silicon NPN - CASE: TO92S MAKE: NEC
Price: £4.79
+ VAT 20% for UK purchases
£4.79
Qty
+ VAT 20% for UK purchases
  • 75 pieces in 1-2 Days
  • More pieces shipped in 14 days
?
Datasheet
2SD1020 Datasheet
Product specifications
Type Transistor Silicon NPN
Case TO92S
Manufacturer NEC
Vbr CBO 30
Vbr CEO 25
Max. PD (W) 350m
C(ob) (F) 13p
Derate (Amb) (W/°C) 2.8m
hfe 110
Ic Max. (A) 700m
Icbo Max. @Vcb Max. (A) 100n
Polarity NPN
Trans. Freq (Hz) Min. 170M
@VCE (test) (V) 1.0
Oper. Temp (°C) Max. 150
@Ic (A) 100m
Pinout Equivalence Number 3-10
Surface Mounted Yes/No NO
Maximum Collector Power Dissipation (Pc) 0.35 W
Maximum Collector-Base Voltage |Vcb| 30 V
Maximum Collector-Emitter Voltage |Vce| 25 V
Maximum Emitter-Base Voltage |Veb| 5 V
Maximum Collector Current |Ic max| 0.7 A
Max. Operating Junction Temperature (Tj) 175 °C
Collector Capacitance (Cc) 13 pF
Transition Frequency (ft): 50 MHz
Forward Current Transfer Ratio (hFE), MIN 70
SKU 81380
