2SD1591
View detailed images (12)

2SD1591

SKU: 2SD1591
2SD1591 Transistor Silicon NPN CASE: SOT186 MAKE: NEC
Datasheet
2SD1591 Datasheet
Product specifications
Type Transistor Silicon NPN
Case SOT186
Manufacturer NEC
Vbr CEO 100
Max. PD (W) 30
t(f) Max. (S) 2.0u-
Max. hFE 30k
Min hFE 1.0k
Ic Max. (A) 10
@Ic (test) (A) 10
Icbo Max. @Vcb Max. (A) 10u
Mat. Silicon Logic
Polarity NPN
Tr Max. (s) 1.0u-
t(stor) Max. (S) 5.0u-
Derate Above 25°C 240m
@VCE (test) 2.0
Oper. Temp (°C) Max. 150
Pinout Equivalence Number 3-15
Surface Mounted Yes/No NO
Maximum Collector Power Dissipation (Pc) 30 W
Maximum Collector-Base Voltage |Vcb| 150 V
Maximum Collector Current |Ic max| 10 A
Max. Operating Junction Temperature (Tj) 150 °C
Forward Current Transfer Ratio (hFE), MIN 6000
SKU 345533
