2SD1802
View detailed images (8)

2SD1802

SKU: 2SD1802
2SD1802 Transistor Silicon NPN CASE: TO252 MAKE: Sanyo Semiconductor
Price:
£7.19 Inc. VAT (£5.99 Ex. VAT)
£7.19 Inc. VAT (£5.99 Ex. VAT)
Qty
  • 7 pieces in 1-2 Days
  • More pieces shipped in 14 days
?
Datasheet
2SD1802 Datasheet
Product specifications
Equivalent 2SD1802T
Type Transistor Silicon NPN
Case TO252
Manufacturer Sanyo Semiconductor
Vbr CBO 60
Vbr CEO 50
Max. PD (W) 15
t(f) Max. (S) 35n-
Max. hFE 560
Min hFE 100
Ic Max. (A) 3.0
@Ic (test) (A) 100m
Icbo Max. @Vcb Max. (A) 1.0u
Polarity NPN
Trans. Freq (Hz) Min. 150M
Oper. Temp (°C) Max. 150
@VCE (V) 2.0
Pinout Equivalence Number 3-15
Surface Mounted Yes/No NO
Maximum Collector Power Dissipation (Pc) 15 W
Maximum Collector-Base Voltage |Vcb| 60 V
Maximum Collector-Emitter Voltage |Vce| 50 V
Maximum Emitter-Base Voltage |Veb| 6 V
Maximum Collector Current |Ic max| 3 A
Max. Operating Junction Temperature (Tj) 150 °C
Collector Capacitance (Cc) 25 pF
Transition Frequency (ft): 150 MHz
Forward Current Transfer Ratio (hFE), MIN 100
SKU 81503
