2SD475
View detailed images (12)

2SD475

SKU: 2SD475
2SD475 Transistor Silicon NPN CASE: TO220AA MAKE: Hitachi
Product specifications
Equivalent 2SD475A
Type Transistor Silicon NPN
Case TO220AA
Manufacturer Hitachi
Vbr CBO 70
Vbr CEO 50
Max. PD (W) 40
Max. hFE 320
Min hFE 35
Ic Max. (A) 4.0
@Ic (test) (A) 1.0
Icbo Max. @Vcb Max. (A) 1.0u
Polarity NPN
R(sat) (Û) 500m
Derate Above 25°C 320m
Trans. Freq (Hz) Min. 7.0M
Oper. Temp (°C) Max. 140
@VCE (V) 4.0
Pinout Equivalence Number 3-10
Surface Mounted Yes/No NO
Maximum Collector Power Dissipation (Pc) 40 W
Maximum Collector-Base Voltage |Vcb| 70 V
Maximum Collector-Emitter Voltage |Vce| 50 V
Maximum Emitter-Base Voltage |Veb| 5 V
Maximum Collector Current |Ic max| 4 A
Max. Operating Junction Temperature (Tj) 150 °C
Collector Capacitance (Cc) 4 pF
Transition Frequency (ft): 3.5 MHz
Forward Current Transfer Ratio (hFE), MIN 35
SKU 542509
