2SD545
View detailed images (12)

2SD545

SKU: 2SD545
2SD545 Transistor Silicon NPN CASE: TO92L MAKE: Sanyo Semiconductor
Price:
£5.75 Inc. VAT (£4.79 Ex. VAT)
£5.75 Inc. VAT (£4.79 Ex. VAT)
Qty
  • 34 pieces in 1-2 Days
  • More pieces shipped in 14 days
?
Datasheet
2SD545 Datasheet
Product specifications
Type Transistor Silicon NPN
Case TO92L
Manufacturer Sanyo Semiconductor
Vbr CBO 25
Vbr CEO 20
Max. PD (W) 500m
C(ob) (F) 15p
hfe 560=
Ic Max. (A) 1.5
Icbo Max. @Vcb Max. (A) 1.0u
Polarity NPN
Trans. Freq (Hz) Min. 180M
@VCE (test) (V) 2.0i
Oper. Temp (°C) Max. 125
@Ic (A) 50m
Pinout Equivalence Number 3-10
Surface Mounted Yes/No NO
Maximum Collector Power Dissipation (Pc) 0.6 W
Maximum Collector-Base Voltage |Vcb| 25 V
Maximum Collector-Emitter Voltage |Vce| 25 V
Maximum Emitter-Base Voltage |Veb| 5 V
Maximum Collector Current |Ic max| 1 A
Max. Operating Junction Temperature (Tj) 125 °C
Collector Capacitance (Cc) 30 pF
Transition Frequency (ft): 180 MHz
Forward Current Transfer Ratio (hFE), MIN 60
SKU 81323
