2SD647
View detailed images (12)

2SD647

SKU: 2SD647
2SD647 Transistor Silicon NPN CASE: TO92L MAKE: Hitachi
Product specifications
Type Transistor Silicon NPN
Case TO92L
Manufacturer Hitachi
Vbr CEO 600
Max. PD (W) 770
t(f) Max. (S) 15u-
Min hFE 100
Ic Max. (A) 100
@Ic (test) (A) 100
Icbo Max. @Vcb Max. (A) 2.0m
Mat. Silicon Logic
Polarity NPN
Tr Max. (s) 3.0u
R(sat) (Û) 25m
t(stor) Max. (S) 20u-
Derate Above 25°C 7.7
Trans. Freq (Hz) Min. 100k
@VCE (test) 5.0
Oper. Temp (°C) Max. 125
Pinout Equivalence Number 3-14
Surface Mounted Yes/No NO
Maximum Collector Power Dissipation (Pc) 770 W
Maximum Collector-Base Voltage |Vcb| 800 V
Maximum Collector-Emitter Voltage |Vce| 600 V
Maximum Emitter-Base Voltage |Veb| 5 V
Maximum Collector Current |Ic max| 100 A
Max. Operating Junction Temperature (Tj) 125 °C
Forward Current Transfer Ratio (hFE), MIN 100
SKU 760204
