2SD827
View detailed images (13)

2SD827

SKU: 2SD827
2SD827 Transistor Silicon NPN CASE: MT200 MAKE: Hitachi
Product specifications
Type Transistor Silicon NPN
Case MT200
Manufacturer Hitachi
Vbr CBO 500
Vbr CEO 500
Max. PD (W) 80
Min hFE 500
Ic Max. (A) 4.0
Polarity NPN
Pinout Equivalence Number 3-15
Surface Mounted Yes/No NO
Maximum Collector Power Dissipation (Pc) 80 W
Maximum Collector-Base Voltage |Vcb| 500 V
Maximum Emitter-Base Voltage |Veb| 7 V
Maximum Collector Current |Ic max| 4 A
Max. Operating Junction Temperature (Tj) 150 °C
Forward Current Transfer Ratio (hFE), MIN 500
SKU 760059
