2SD94
View detailed images (12)

2SD94

SKU: 2SD94
2SD94 Transistor Silicon NPN CASE: SOT9 MAKE: Sanken
Datasheet
2SD94 Datasheet
Product specifications
Type Transistor Silicon NPN
Case SOT9
Manufacturer Sanken
Vbr CBO 200
Vbr CEO 80
Max. PD (W) 20
Max. hFE 40-
Min hFE 20
Ic Max. (A) 3.0
@Ic (test) (A) 1.0
Polarity NPN
Derate Above 25°C 160m
@VCE (V) 4.0
Pinout Equivalence Number 3-14
Surface Mounted Yes/No NO
Maximum Collector Power Dissipation (Pc) 20 W
Maximum Collector-Base Voltage |Vcb| 200 V
Maximum Collector-Emitter Voltage |Vce| 85 V
Maximum Emitter-Base Voltage |Veb| 10 V
Maximum Collector Current |Ic max| 3 A
Max. Operating Junction Temperature (Tj) 125 °C
Transition Frequency (ft): 1 MHz
Forward Current Transfer Ratio (hFE), MIN 20
SKU 346161
