ROHM Semiconductor BA6144 LED VU Level Meter Driver IC

The BA6144 manufactured by ROHM Semiconductor is a highly efficient, monolithic 5-point LED VU level meter driver integrated circuit designed primarily for audio display applications. Packaged in a compact, space-saving 9-pin Single Inline Package (SIP-9), this IC is an industry standard for driving bar-type or ladder LED visual level indicators.

Whether you are performing a vintage audio repair on a stereo cassette deck, servicing mixing consoles, or designing custom signal strength indicators, the ROHM BA6144 offers reliable current control and an accurate logarithmic VU scale display range from -13dB to +17dB.

Featuring an onboard rectifier amplifier, the BA6144 can process direct AC or DC audio input signals without requiring complex external conversion components. Its constant-current outputs guarantee uniform LED brightness, isolating your display elements from fluctuations or drops in the main power supply voltage.

Key Features & Technical Specifications:

• Manufacturer: ROHM Semiconductor
• Part Number / MPN: BA6144
• Package Type: SIP-9 (9-Pin Single Inline Package)
• Display Type: 5-Point Logarithmic VU Scale (-13dB to +17dB)
• Operating Voltage Range: Wide supply voltage operating window from 5.5V to 16V (12V Typical)
• Input Compatibility: Built-in rectifier amplifier handles direct AC or DC inputs
• Output Configuration: Low-flicker constant-current outputs for stable LED illumination
• Mounting Type: Through-Hole

Common Applications:

• Audio equipment volume indicators (VU Meters)
• Vintage stereo receiver and tape deck restoration
• Analog radio receiver signal strength meters (S-Meters)
• Industrial automation diagnostics and battery voltage monitors

Buy Genuine ROHM BA6144 Components

Find genuine, high-quality ROHM BA6144 ICs in stock at Little Diode. We specialize in sourcing rare, obsolete, and standard electronic components for hobbyists, repair shops, and industrial electronics manufacturers. Secure worldwide shipping is available on all components.
