BC509
View detailed images (12)

BC509

SKU: BC509
BC509 Transistor Silicon NPN CASE: TO106 MAKE: SGS Thomson
Product specifications
Type Transistor Silicon NPN
Case TO106
Manufacturer SGS Thomson
Vbr CBO 35
Vbr CEO 60
Max. PD (W) 360m
C(ob) (F) 3.5p
Derate (Amb) (W/°C) 3.6m
hfe 240
Ic Max. (A) 200m
Icbo Max. @Vcb Max. (A) 15u
Polarity NPN
Trans. Freq (Hz) Min. 200M
@VCE (test) (V) 5.0
Oper. Temp (°C) Max. 125
@Ic (A) 2.0m
Pinout Equivalence Number N/A
Surface Mounted Yes/No NO
Maximum Collector Power Dissipation (Pc) 0.2 W
Maximum Collector-Base Voltage |Vcb| 60 V
Maximum Collector-Emitter Voltage |Vce| 40 V
Maximum Emitter-Base Voltage |Veb| 6 V
Maximum Collector Current |Ic max| 0.18 A
Max. Operating Junction Temperature (Tj) 150 °C
Collector Capacitance (Cc) 6 pF
Transition Frequency (ft): 200 MHz
Forward Current Transfer Ratio (hFE), MIN 200
SKU 742220
