BD109
View detailed images (12)

BD109

SKU: BD109
BD109 Transistor Silicon NPN - CASE: SOT9 MAKE: Discrete Semiconductor Industries
Price: £11.99
+ VAT 20% for UK purchases
£11.99
Qty
+ VAT 20% for UK purchases
  • 8 pieces in 1-2 Days
  • More pieces shipped in 14 days
Product specifications
Type Transistor Silicon NPN
Manufacturer Discrete Semiconductor Industries - DSI
Case SOT9
Vbr CBO 400
Vbr CEO 40
Ckts Per Dev. 1
Max. PD (W) 15
t(f) Max. (S) 900n
Max. hFE 120
Min hFE 20
Ic Max. (A) 2.0
@Ic (test) (A) 10
Icbo Max. @Vcb Max. (A) 100n
Polarity NPN
Tr Max. (s) 1.2u
Therm Res. (J-C) 300m
Derate Above 25°C 142m
VCE(sat) Max. 2.5
Trans. Freq (Hz) Min. 50M
Oper. Temp (°C) Max. 125
Isolated Case (Y/N) Yes
Pinout Equivalence Number N/A
Surface Mounted Yes/No NO
Maximum Collector Power Dissipation (Pc) 18 W
Maximum Collector-Base Voltage |Vcb| 60 V
Maximum Collector-Emitter Voltage |Vce| 40 V
Maximum Emitter-Base Voltage |Veb| 5 V
Maximum Collector Current |Ic max| 3 A
Max. Operating Junction Temperature (Tj) 175 °C
Transition Frequency (ft): 30 MHz
Forward Current Transfer Ratio (hFE), MIN 40
SKU 313704
