BD663A
View detailed images (12)

BD663A

SKU: BD663A
BD663A Transistor Silicon NPN CASE: TO220AA MAKE: SGS Thomson
Product specifications
Type Transistor Silicon NPN
Case TO220AA
Manufacturer SGS Thomson
Vbr CEO 45
Max. PD (W) 1.8
Max. hFE 250
Min hFE 25
Ic Max. (A) 10
@Ic (test) (A) 2.0
Icbo Max. @Vcb Max. (A) 5.0m
Polarity NPN
R(sat) (Û) 250m
Derate Above 25°C 598m
Oper. Temp (°C) Max. 140
@VCE (V) 2.0
Pinout Equivalence Number 3-15
Surface Mounted Yes/No NO
Maximum Collector Power Dissipation (Pc) 75 W
Maximum Collector-Base Voltage |Vcb| 60 V
Maximum Collector-Emitter Voltage |Vce| 40 V
Maximum Emitter-Base Voltage |Veb| 5 V
Maximum Collector Current |Ic max| 10 A
Max. Operating Junction Temperature (Tj) 150 °C
Transition Frequency (ft): 3 MHz
Forward Current Transfer Ratio (hFE), MIN 20
SKU 573663
