BD679AG
View detailed images (4)

BD679AG

SKU: BD679AG
BD679AG Transistor Silicon NPN CASE: TO225 MAKE: Generic
Product specifications
Type Transistor Silicon NPN
Case TO225
Manufacturer Generic
Polarity NPN
Maximum Collector Power Dissipation (Pc) 40 W
Maximum Collector-Base Voltage |Vcb| 80 V
Maximum Collector-Emitter Voltage |Vce| 80 V
Maximum Emitter-Base Voltage |Veb| 5 V
Maximum Collector Current |Ic max| 4 A
Max. Operating Junction Temperature (Tj) 150 °C
Forward Current Transfer Ratio (hFE), MIN 750
SKU 737738
