BDX22

SKU: BDX22
BDX22 Transistor Silicon NPN CASE: SOT9 MAKE: SGS Thomson
Product specifications
Type Transistor Silicon NPN
Case SOT9
Manufacturer SGS Thomson
Vbr CBO 160
Vbr CEO 140
Max. PD (W) 37
Max. hFE 250
Min hFE 20
Ic Max. (A) 10
@Ic (test) (A) 500m
Icbo Max. @Vcb Max. (A) 1.0m
Polarity NPN
Derate Above 25°C 250m
Oper. Temp (°C) Max. 175
@VCE (V) 4.0
Pinout Equivalence Number N/A
Surface Mounted Yes/No NO
Maximum Collector Power Dissipation (Pc) 37.5 W
Maximum Collector-Base Voltage |Vcb| 160 V
Maximum Collector-Emitter Voltage |Vce| 140 V
Maximum Emitter-Base Voltage |Veb| 7 V
Maximum Collector Current |Ic max| 10 A
Max. Operating Junction Temperature (Tj) 200 °C
Transition Frequency (ft): 0.8 MHz
Forward Current Transfer Ratio (hFE), MIN 20
SKU 573525
