BFQ255A
View detailed images (5)

BFQ255A

SKU: BFQ255A
BFQ255A Transistor Silicon PNP CASE: SOT128 MAKE: Philips
Datasheet
BFQ255A Datasheet
Product specifications
Type Transistor Silicon PNP
Case SOT128
Manufacturer Philips
Vbr CBO 115
Mat. Silicon Logic
Polarity PNP
PD Max. (W) 3.0
Coll. (or drain) Current Max. 300m
Oper. Temp (°C) Max. 175
Pinout Equivalence Number 3-10
Surface Mounted Yes/No NO
Maximum Collector Power Dissipation (Pc) 3 W
Maximum Collector-Base Voltage |Vcb| 115 V
Maximum Collector-Emitter Voltage |Vce| 70 V
Maximum Collector Current |Ic max| 0.3 A
Max. Operating Junction Temperature (Tj) 175 °C
Transition Frequency (ft): 1300 MHz
Forward Current Transfer Ratio (hFE), MIN 25
SKU 20195
