BU705D
View detailed images (12)

BU705D

SKU: BU705D
BU705D Transistor Silicon NPN CASE: TO3PF MAKE: Generic
Product specifications
Type Transistor Silicon NPN
Case TO3PF
Manufacturer Generic
Vbr CEO 700
Max. PD (W) 75
t(f) Max. (S) 900n
Min hFE 2.2
Ic Max. (A) 4.0
@Ic (test) (A) 2.0
Icbo Max. @Vcb Max. (A) 1.0m
Polarity NPN
Derate Above 25°C 800m
Trans. Freq (Hz) Min. 7.0M
Oper. Temp (°C) Max. 135
@VCE (V) 5.0
Pinout Equivalence Number 3-15
Surface Mounted Yes/No NO
Maximum Collector Power Dissipation (Pc) 78 W
Maximum Collector-Base Voltage |Vcb| 1500 V
Maximum Collector-Emitter Voltage |Vce| 700 V
Maximum Collector Current |Ic max| 2.5 A
Max. Operating Junction Temperature (Tj) 150 °C
Collector Capacitance (Cc) 80 pF
Transition Frequency (ft): 7.5 MHz
Forward Current Transfer Ratio (hFE), MIN 2.25
SKU 139667
