CS720A Transistor Silicon NPN CASE: TO106 MAKE: TAG Semiconductors
Product specifications
Type Transistor Silicon NPN
Case TO106
Manufacturer TAG Semiconductors
Vbr CBO 120
Vbr CEO 80
Max. PD (W) 300m
C(ob) (F) 15p
hfe 40
Icbo Max. @Vcb Max. (A) 10n
Polarity NPN
Trans. Freq (Hz) Min. 80M
@VCE (test) (V) 10
@Ic (A) 150m
Pinout Equivalence Number N/A
Surface Mounted Yes/No NO
Maximum Collector Power Dissipation (Pc) 0.3 W
Maximum Collector-Base Voltage |Vcb| 120 V
Maximum Collector-Emitter Voltage |Vce| 18 V
Maximum Emitter-Base Voltage |Veb| 5 V
Maximum Collector Current |Ic max| 0.1 A
Max. Operating Junction Temperature (Tj) 135 °C
Collector Capacitance (Cc) 15 pF
Transition Frequency (ft): 80 MHz
Forward Current Transfer Ratio (hFE), MIN 28
SKU 580327
