DM74LS242N

DM74LS242N

SKU: DM74LS242N
DM74LS242N Logic IC CASE: DIP16 MAKE: National Semiconductor - NSC
Product specifications
Type Logic IC
Case DIP16
Manufacturer National Semiconductor - NSC
Inp Thrshld Hi (V) 3.4
Inp Thrshld Lo (V) 2.4
Mode I/O D or S Single-End
tPD Max. (S) 18n
Nom. Neg Supp 0.0
Nom. Pos. Supp 5.0
Tech. TTL Integrated Circuit
Oper. Temp (°C) Min 0
Oper. Temp (°C) Max. 70
@IOL (A) 24m
VOL Max. (Drvr) 3.4
VOL Max. (Rcvr) 0.8
VOH Min (Rcvr) 2.0
Pinout Equivalence Number 14-150
Surface Mounted Yes/No NO
SKU 972491
