DS1687J8
View detailed images (13)

DS1687J8

SKU: DS1687J8
DS1687J8 Integrated Circuit - Case: DIP8 Make: National Semiconductor - NSC
+ VAT 20% for UK purchases
Product specifications
Type Integrated Circuit
Case DIP8
Manufacturer National Semiconductor - NSC
Vih Min (V) 2.0
Vil Max. (V) 0.8
Inp Logic Family C/PMOS,D/T
Output Config Open-Coll.
VOL Max. 1.3
Outp Transis. Ion Max. 300m
PD Max. (W) 140m
tPD Max. (S) 1.0u
Nom. Supp (V) 5.0
Tech. TTL Integrated Circuit
Logic Funct. NAND
Oper. Temp (°C) Min -55
Oper. Temp (°C) Max. 100
VOH Max. 56
@Iol (A) 300m
Pinout Equivalence Number 8-42
No. of Pins 8
Surface Mounted Yes/No NO
SKU 414452
