DS3691N

DS3691N

SKU: DS3691N
DS3691N Integrated Circuit CASE: DIP16 MAKE: National Semiconductor - NSC
Datasheet
DS3691N Datasheet
Product specifications
Type Integrated Circuit
Case DIP16
Manufacturer National Semiconductor - NSC
Ckts Per Dev. 2
Output Config 3-State
Outp Volt Hi Typ. 2.4
Outp Volt Lo Typ. -2.4
tPD Max. (S) 300n
Nom. Neg Supp 7.0
Nom. Pos. Supp 7.0*
Tech. TTL Integrated Circuit
Logic Funct. Inv/Noninv
Oper. Temp (°C) Min 0
Oper. Temp (°C) Max. 70
Pinout Equivalence Number 16-408
Descript Meets EIA RS-422/RS-423
Surface Mounted Yes/No NO
SKU 169400
