GBU6D
View detailed images (4)

GBU6D

SKU: GBU6D
GBU6D Bridge Rectifier Diode CASE: Standard MAKE: Fairchild Semiconductor
Price:
£4.79 Inc. VAT (£3.99 Ex. VAT)
£4.79 Inc. VAT (£3.99 Ex. VAT)
Qty
  • More pieces shipped in 14 days
?
Datasheet
GBU6D Datasheet
Product specifications
Type Bridge Rectifier Diode
Case Standard
Manufacturer Fairchild Semiconductor
@Temp. (test) (°C) 100#
Ir @ Diff. Temp (A) 500u
VRRM 200
1-Cycle Surge Current (A) 175
@Temp (test) (°C) 125
@Temp. (test) for Vf) 25
Vf Max. 1.0
Ir @25°C 5.0u
I(out) (If AVG) Max. 6.0
@Volts (test) (V) 200
@If (test) 6.0
Oper. Temp (°C) Max. 150
Surface Mounted Yes/No NO
SKU 91661
