KSA636
View detailed images (5)

KSA636

SKU: KSA636
KSA636 Transistor Silicon PNP CASE: SOT128 MAKE: Samsung
Product specifications
Type Transistor Silicon PNP
Case SOT128
Manufacturer Samsung
Vbr CBO 70
Vbr CEO 45
Max. PD (W) 10
Max. hFE 240
Min hFE 40
Ic Max. (A) 2.0
@Ic (test) (A) 500m
Icbo Max. @Vcb Max. (A) 1.0u
Polarity PNP
Oper. Temp (°C) Max. 140
@VCE (V) 5.0
Pinout Equivalence Number 3-15
Surface Mounted Yes/No NO
Maximum Collector Power Dissipation (Pc) 10 W
Maximum Collector-Emitter Voltage |Vce| 45 V
Maximum Collector Current |Ic max| 2 A
Max. Operating Junction Temperature (Tj) 150 °C
Forward Current Transfer Ratio (hFE), MIN 40
SKU 569303
