MC1414D

MC1414D

SKU: MC1414D
MC1414D Logic IC CASE: SO MAKE: Motorola Semiconductor
Product specifications
Type Logic IC
Case SO
Manufacturer Motorola Semiconductor
I(io) Max. (A) 7.5u
V(io) Max. (V) 6.5m
PD Max. (W) 1.0
Volt Gain Min 70
Inp Bias Curr. Max. (A) 40u
Com Mode Inp Range (VICR) 7.0
Oper. Temp (°C) Min 0
Oper. Temp (°C) Max. 75
t(resp) (S) 40n
Strobe Inp (Y/N) Yes
Pinout Equivalence Number 14-85
Surface Mounted Yes/No YES
SKU 247085
