MC6800CS
View detailed images (12)

MC6800CS

SKU: MC6800CS
MC6800CS Integrated Circuit CASE: DIP48 MAKE: Motorola Semiconductor
Product specifications
Type Integrated Circuit
Case DIP48
Manufacturer Motorola Semiconductor
Mem. Addr Rnge 64k
No.of Addr. Modes 7
No. of I/O Lines 16
I/O Line Types Byte/MUXed
Max. Inst. Len (bits) 24
Min Inst. Len (bits) 8
No. of Intrpt Lines 2
No. of Intrpt (NMI) 1
Intrpt Types Prty/Ext V
No. of Intrpt (mask) 1
fClk Max. (Hz) 1.0M
fClk Min (Hz) 100k
Nom. Supp Volt 5.0
Tech. NMOS Integrated Circuit
Oper. Temp (°C) Min -25
Oper. Temp (°C) Max. 85
Pinout Equivalence Number 40-167
No. of Pins 40
Surface Mounted Yes/No NO
SKU 672836
