MC68HC811E2MP
View detailed images (12)

MC68HC811E2MP

SKU: MC68HC811E2MP
MC68HC811E2MP Integrated Circuit CASE: DIP48 MAKE: Motorola Semiconductor
Product specifications
Type Integrated Circuit
Case DIP48
Manufacturer Motorola Semiconductor
Mem. Addr Rnge 2k
No.of Addr. Modes 6
No. of I/O Lines 38
I/O Line Types Byte/MUXed
Max. Inst. Len (bits) 16
Min Inst. Len (bits) 8
No. of Intrpt Lines 2
No. of Intrpt (NMI) 3
Intrpt Types Maskab/Non
No. of Intrpt (mask) 15
fClk Max. (Hz) 2.0M
No. of I/O Ports 5
Nom. Supp Volt 5.0
Tech. CMOS Integrated Circuit
On-Chip RAM (Bytes) 256
Oper. Temp (°C) Min -40
Oper. Temp (°C) Max. 125
Pinout Equivalence Number 48-202
No. of Pins 48
Surface Mounted Yes/No NO
SKU 1136209
