MD2310FX
View detailed images (4)

MD2310FX

SKU: MD2310FX
MD2310FX Transistor Silicon NPN CASE: TO247F MAKE: SGS Thomson
Price:
£4.79 Inc. VAT (£3.99 Ex. VAT)
£4.79 Inc. VAT (£3.99 Ex. VAT)
Qty
  • 3 pieces in 1-2 Days
  • More pieces shipped in 14 days
?
Product specifications
Type Transistor Silicon NPN
Case TO247F
Manufacturer SGS Thomson
Polarity NPN
Maximum Collector Power Dissipation (Pc) 62 W
Maximum Collector-Base Voltage |Vcb| 1500 V
Maximum Collector-Emitter Voltage |Vce| 700 V
Maximum Emitter-Base Voltage |Veb| 9 V
Maximum Collector Current |Ic max| 14 A
Max. Operating Junction Temperature (Tj) 150 °C
Forward Current Transfer Ratio (hFE), MIN 5.5
SKU 432462
