MT100
View detailed images (4)

MT100

SKU: MT100
MT100 SemiConductor CASE: DO34 MAKE: General Instrument
Product specifications
Type SemiConductor
Case DO34
Manufacturer General Instrument
Vbr CBO 25
Vbr CEO 20
Max. PD (W) 150m
C(ob) (F) 5.0p
Derate (Amb) (W/°C) 1.0m
hfe 45
Icbo Max. @Vcb Max. (A) .50u
@Temp. (test) (°C) 110#
Ir @ Diff. Temp (A) .05m
VRRM 1.0k
1-Cycle Surge Current (A) 10
@Temp (test) (°C) 150
@Temp. (test) for Vf) 25#
Vf Max. 1.0
Ir @25°C .50u
I(out) (If AVG) Max. .50
Trans. Freq (Hz) Min. 750M
@VCE (test) (V) 1.0
@Volts (test) (V) 1.0k
@If (test) .40
Oper. Temp (°C) Max. 150
@Ic (A) 10m
Pinout Equivalence Number N/A
Surface Mounted Yes/No NO
SKU 661163
