PZTA14
View detailed images (8)

PZTA14

SKU: PZTA14
PZTA14 Transistor Silicon NPN CASE: SOT223 MAKE: ON Semiconductor
Product specifications
Type Transistor Silicon NPN
Case SOT223
Manufacturer ON Semiconductor
Vbr CEO 30
Max. PD (W) 1.5
Min hFE 10k
Ic Max. (A) 300m
@Ic (test) (A) 10m
Icbo Max. @Vcb Max. (A) 0.1u
Mat. Silicon Logic
Polarity NPN
Trans. Freq (Hz) Min. 125M
@VCE (test) 5.0
Oper. Temp (°C) Max. 150
Pinout Equivalence Number 4-105
Surface Mounted Yes/No YES
Maximum Collector Power Dissipation (Pc) 1.25 W
Maximum Collector-Base Voltage |Vcb| 30 V
Maximum Collector-Emitter Voltage |Vce| 30 V
Maximum Emitter-Base Voltage |Veb| 10 V
Maximum Collector Current |Ic max| 0.5 A
Max. Operating Junction Temperature (Tj) 150 °C
Transition Frequency (ft): 125 MHz
Forward Current Transfer Ratio (hFE), MIN 20000
SMD Transistor Code P1N
SKU 279189
