SN54LS654F

SN54LS654F

SKU: SN54LS654F
SN54LS654F Integrated Circuit CASE: SO24 MAKE: Texas Instruments
Product specifications
Type Integrated Circuit
Case SO24
Manufacturer Texas Instruments
Inp Thrshld Hi (V) 2.0
Inp Thrshld Lo (V) 0.8
Mode I/O D or S Single-End
tPD Max. (S) 55n
Nom. Neg Supp 0.0
Nom. Pos. Supp 5.0
Tech. TTL Integrated Circuit
Oper. Temp (°C) Min -55
Oper. Temp (°C) Max. 125
@IOL (A) 12m
VOL Max. (Drvr) 0.4
VOL Max. (Rcvr) 0.4
VOH Min (Rcvr) 2.0
Pinout Equivalence Number 24-410
No. of Pins 24
Surface Mounted Yes/No YES
SKU 980188
